User-defined Playground

OpenBao vs Vault Playground

A clash of titans: OpenBao and Vault side by side for easy comparison.

Playground Parameters

OpenBao vs Vault playground: A clash of titans: OpenBao and Vault side by side for easy comparison.

This playground lets you experiment with OpenBao and Vault in a single environment.

Compare how they work and explore their similarities and differences.

Dev mode

Both services are configured to run in dev mode by default, meaning:

  • Initialized and unsealed - The server will be automatically initialized and unsealed.
  • In-memory storage - All data is stored (encrypted) in-memory.
  • KV engine enabled at secret/

If you'd prefer to run the services "normally", see the Setup without dev mode section.

For more feature demos, check out the Other playgrounds section.

You can read more about the properties of the dev server here:

Connecting

Connect to each service using the following commands:

OpenBao
Vault
bao status
vault status

💡 The terminal session should be configured to connect the locally running service.

The root token for connecting from other clients (e.g., the embedded UIs) is iximiuz.

If you're feeling adventurous, try connecting from one client to the other service:

OpenBao
Vault
bao status -address http://vault:8200
vault status -address http://openbao:8200

Configuration

To experiment with custom configurations, place your config files in the following location (ensure they're owned by the service user):

OpenBao
Vault

Config dir: /etc/openbao/config.d/

chown -R openbao:openbao /etc/openbao/config.d/

Config dir: /etc/vault.d/config.d/

chown -R vault:vault /etc/vault.d/config.d/

Other playgrounds

Other playgrounds showcasing features not available here: coming soon!

Setup without dev mode

If you choose to run the service in "normal" mode (i.e. Dev mode disabled), a few extra steps are needed to replicate the dev mode setup.

These steps are outlined in this tutorial.

tl;dr

Review the contents of /opt/playground/setup.sh, then run it.

Details

OpenBaoVault
Hostnameopenbaovault
IP Address172.16.0.2172.16.0.3
Config/etc/openbao/openbao.hcl/etc/vault.d/vault.hcl
Restartsystemctl restart openbaosystemctl restart vault
Plugin dir/var/openbao/plugins/var/vault/plugins
