Testing and releasing Helm charts with Dagger

Learn how to test, package and release Helm charts using Dagger.

Prerequisites

This tutorial assumes you're already familiar with the basics of Dagger.

If you're new to Dagger or need a quick refresher, we recommend starting with the Quickstart Guide.

dagger login [your_org]

Preparations

First, let's switch to the dagger tab and change the directory to demo:

cd demo

Make sure the application can be built and functions properly:

dagger call serve up --ports 8080:80

Go to the Service tab. You should see the application running.

Go back to the dagger tab and hit q or Ctrl+C to stop the application.

Installing the Helm module

If you're already comfortable with Helm, you can set up your own pipelines using Dagger and the official Helm container image. However, this isn't much better than writing a vendor-specific YAML file and invoking the Helm binary directly.

Dagger’s real power lies in its modules, which provide clean, high-level APIs—removing the need to call binaries in containers.

Fortunately, there’s already a Helm module available on Daggerverse. It offers a convenient API for managing Helm charts directly in your Dagger functions:

dagger install github.com/sagikazarmark/daggerverse/helm

It's time to write some code using the newly installed Helm module. Go to the IDE tab and open the demo/.dagger/main.go file.

Add the following code to the main.go file:

// Create a Helm chart object.
func (m *Tutorial) chart() *dagger.HelmChart {
    chart := m.Source.Directory("deploy/charts/demo-dagger-helm")

    return dag.Helm().Chart(chart)
}

The rest of the tutorial will rely on this utility function extensively.

dag.Helm(dagger.HelmOpts{Version: "3.16.1"})

Linting Helm charts

Part of ensuring the quality of your Helm charts is running the built-in linter that checks for common mistakes and best practices.

Staying in the IDE tab and the demo/.dagger/main.go file, create a new Lint function:

// Lint the Helm chart.
func (m *Tutorial) Lint(ctx context.Context) (string, error) {
    return m.chart().Lint().Stdout(ctx)
}

You can now call the Lint function on the dagger tab:

dagger call lint

Testing Helm charts

Testing Helm charts is more involved than simply linting them, especially when you want to verify that the application is both deployed correctly and fully functional. You’ll need a Kubernetes cluster for the installation process, as well as a container registry to push the application image for Kubernetes to pull from. Ideally, this registry should be local to avoid pushing images to remote registries during CI runs.

Fortunately, we can rely on existing modules from the Daggerverse to streamline this process:

dagger install github.com/marcosnils/daggerverse/k3s
dagger install github.com/sagikazarmark/daggerverse/registry

The k3s module (lightweight Kubernetes) will run a k3s cluster in Dagger, while the registry module provides a place to push your application image so Kubernetes can pull it as needed.

Let’s start putting the test function together. First up, build a chart package that can be deployed to Kubernetes:

// Test the Helm chart.
func (m *Tutorial) Test(ctx context.Context) error {
    app := m.Build(ctx)
    chart := m.chart().Package()

    // ...

    return nil
}

Next, set up a container registry service for the application image:

    registry := dag.Registry().Service()

    // Push the container image to a local registry.
    _, err := dag.Container().From("quay.io/skopeo/stable").
        WithServiceBinding("registry", registry).
        WithMountedFile("/work/image.tar", app.AsTarball()).
        WithEnvVariable("CACHE_BUSTER", time.Now().String()).
        WithExec([]string{"skopeo", "copy", "--all", "--dest-tls-verify=false", "docker-archive:/work/image.tar", "docker://registry:5000/demo-dagger-helm:latest"}).
        Sync(ctx)
    if err != nil {
        return err
    }

Set up a k3s cluster with the registry acting as a mirror where Kubernetes can pull the image from:

    // Configure k3s to use the local registry.
    k8s := dag.K3S("test").With(func(k *dagger.K3S) *dagger.K3S {
        return k.WithContainer(
            k.Container().
            WithEnvVariable("BUST", time.Now().String()).
            WithExec([]string{"sh", "-c", `
cat <<EOF > /etc/rancher/k3s/registries.yaml
mirrors:
  "registry:5000":
    endpoint:
    - "http://registry:5000"
EOF`}).
            WithServiceBinding("registry", registry),
        )
    })

    // Start the Kubernetes cluster.
    _, err = k8s.Server().Start(ctx)
    if err != nil {
        return err
    }

Finally, install the chart on the cluster and run the tests:

    const values = `
image:
    repository: registry:5000/demo-dagger-helm
    tag: latest
`

    _, err = chart.
        WithKubeconfigFile(k8s.Config()).
        Install("demo", dagger.HelmPackageInstallOpts{
            Wait: true,
            Values: []*dagger.File{
                dag.Directory().WithNewFile("values.yaml", values).File("values.yaml"),
            },
        }).
        Test(ctx, dagger.HelmReleaseTestOpts{
            Logs: true,
        })
    if err != nil {
        return err
    }

// Test the Helm chart.
func (m *Tutorial) Test(ctx context.Context) error {
    app := m.Build(ctx)
    chart := m.chart().Package()

    registry := dag.Registry().Service()

    // Push the container image to a local registry.
    _, err := dag.Container().From("quay.io/skopeo/stable").
        WithServiceBinding("registry", registry).
        WithMountedFile("/work/image.tar", app.AsTarball()).
        WithEnvVariable("CACHE_BUSTER", time.Now().String()).
        WithExec([]string{"skopeo", "copy", "--all", "--dest-tls-verify=false", "docker-archive:/work/image.tar", "docker://registry:5000/demo-dagger-helm:latest"}).
        Sync(ctx)
    if err != nil {
        return err
    }

    // Configure k3s to use the local registry.
    k8s := dag.K3S("test").With(func(k *dagger.K3S) *dagger.K3S {
        return k.WithContainer(
            k.Container().
            WithEnvVariable("BUST", time.Now().String()).
            WithExec([]string{"sh", "-c", `
cat <<EOF > /etc/rancher/k3s/registries.yaml
mirrors:
  "registry:5000":
    endpoint:
    - "http://registry:5000"
EOF`}).
            WithServiceBinding("registry", registry),
        )
    })

    // Start the Kubernetes cluster.
    _, err = k8s.Server().Start(ctx)
    if err != nil {
        return err
    }

    const values = `
image:
    repository: registry:5000/demo-dagger-helm
    tag: latest
`

    _, err = chart.
        WithKubeconfigFile(k8s.Config()).
        Install("demo", dagger.HelmPackageInstallOpts{
            Wait: true,
            Values: []*dagger.File{
                dag.Directory().WithNewFile("values.yaml", values).File("values.yaml"),
            },
        }).
        Test(ctx, dagger.HelmReleaseTestOpts{
            Logs: true,
        })
    if err != nil {
        return err
    }

    return nil
}

You can now call the Test function on the dagger tab:

dagger call test

Releasing Helm charts

Pushing the chart to an OCI registry marks the final step in the development lifecycle. The helm module is fully equipped to handle this task:

// Package and release the Helm chart (and the application).
func (m *Tutorial) Release(ctx context.Context, version string) error {
    const registry = "registry.iximiuz.com"

    _, err := m.Build(ctx).
        Publish(ctx, fmt.Sprintf("%s/demo-dagger-helm:%s", registry, version))
    if err != nil {
        return err
    }

    err = m.chart().
        Package(dagger.HelmChartPackageOpts{
            Version:    strings.TrimPrefix(version, "v"),
            AppVersion: version,
        }).
        Publish(ctx, fmt.Sprintf("oci://%s/helm-charts", registry))
    if err != nil {
        return err
    }

    return nil
}

Typically, pushing release artifacts is done by a CI/CD pipeline. However, (for the purposes of this tutorial) you can also do it manually:

dagger call release --version=v1.0.0

_, err := m.Build(ctx).
        WithRegistryAuth("example.com", username, password).
        Publish(ctx, fmt.Sprintf("%s/demo-dagger-helm:%s", registry, version))

    // ..

    err = m.chart().
        Package(/*...*/).
        WithRegistryAuth("example.com", username, password).
        Publish(ctx, fmt.Sprintf("oci://%s/helm-charts", registry))

Summary

In this tutorial, we explored how to build a CI pipeline for Helm charts using Dagger. We walked through testing, linting, and releasing charts, highlighting real-world use cases such as pinning versions and configuring registry authentication. By following this workflow, you can easily integrate these practices into an existing Dagger pipeline or use them as the foundation for a new one.
