Customer - Ingest and verify BoB

THIS PART WILL SHOW HOW BOBCTL IMPLEMENTS BOB-TEST

Welcome back to kubernetes. Now, we are switching sides and becoming a customer who uses the webapp product.

We now use k3s for the first time, which is significantly different from the vendor setup to showcase how the BoB translates across tech-stacks.

In this first part on the customer side, we need to verify and unpack the BoB.

What this means is that there is a part where we pull the artefact and verify the signature. Then, we test deploy the application including the BoB and verify the runtime-deployment.

Afterwards, the customer may choose to use the runtime-rules during production or adopt them to their own liking.

It is crucial, that the vendor can only supply a BoB for a subset of all possible runtime configurations, this part can be directly verified during the BoB test, the customer is expected to modify the bob.values or merge the bob.yaml into their own environment.

Diagram: BoB installation and verification

Part 1 Verfication aka BoB Test

We imagine that the BoB-test would be run via automation on a lower environment, on which load-tests are being conducted. Just like in most installations, we assume the values will be iteratively adapted until stable.

(mermaid remove due to timeouts)

Once considered stable, the merged bob.yaml and the adapted bob.values can be used in production , without the test phase.

WIP: we shall assume we fetched the artefact and upacked the metadata

git clone https://github.com/k8sstormcenter/honeycluster.git
cd honeycluster
git checkout 162-write-bob-testscript-for-anyone-to-contribute-a-bob-for-the-pingapps

bobctl pull

oras manifest fetch $IMAGE --pretty --plain-http
untar ...

bobctl test

make kubescape-bob-kind
sudo apt install -y python3-yaml
cd traces/kubescape-verify/attacks/bob
python3 bob.py
kubectl apply -f processed_bob_generated.yaml

applicationprofile.spdx.softwarecomposition.kubescape.io/replicaset-webapp-d87cdd796 created

In a new tab, tail the kubescape logs

kubectl logs -n honey -l app=node-agent -f -c node-agent

Back in the first tab:

kubectl apply -f bob.test

laborant@dev-machine:bob$ kubectl apply -f bob.test
deployment.apps/webapp created
deployment.apps/testapp created
service/webapp created
role.rbac.authorization.k8s.io/webapp-role created
rolebinding.rbac.authorization.k8s.io/webapp-role-binding created

Over in the kubescape logs we see two alerts:

{"BaseRuntimeMetadata":{"alertName":"Unexpected system call","arguments":{"syscall":"gettid"},"infectedPID":11278,"md5Hash":"4e79f11b07df8f72e945e0e3b3587177","sha1Hash":"b361a04dcb3086d0ecf960d3acaa776c62f03a55","severity":1,"size":"730 kB","timestamp":"2025-05-14T18:44:43.123308596Z","trace":{}},"CloudMetadata":null,"RuleID":"R0003","RuntimeK8sDetails":{"clusterName":"honeycluster","containerName":"ping-app","hostNetwork":false,"namespace":"default","containerID":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5","podName":"webapp-d87cdd796-tcml8","podNamespace":"default","workloadName":"webapp","workloadNamespace":"default","workloadKind":"Deployment"},"RuntimeProcessDetails":{"processTree":{"pid":11278,"cmdline":"apache2 -DFOREGROUND","comm":"apache2","ppid":11128,"pcomm":"containerd-shim","uid":0,"gid":0,"startTime":"0001-01-01T00:00:00Z","cwd":"/var/www/html","path":"/usr/sbin/apache2"},"containerID":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5"},"event":{"runtime":{"runtimeName":"containerd","containerId":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5"},"k8s":{"node":"node-02","namespace":"default","podName":"webapp-d87cdd796-tcml8","podLabels":{"app":"webapp","pod-template-hash":"d87cdd796"},"containerName":"ping-app","owner":{}},"timestamp":1747248283123308596,"type":"normal"},"level":"error","message":"Unexpected system call: gettid","msg":"Unexpected system call","time":"2025-05-14T18:44:43Z"}
{"BaseRuntimeMetadata":{"alertName":"Unexpected system call","arguments":{"syscall":"tkill"},"infectedPID":11278,"md5Hash":"4e79f11b07df8f72e945e0e3b3587177","sha1Hash":"b361a04dcb3086d0ecf960d3acaa776c62f03a55","severity":1,"size":"730 kB","timestamp":"2025-05-14T18:44:43.133316166Z","trace":{}},"CloudMetadata":null,"RuleID":"R0003","RuntimeK8sDetails":{"clusterName":"honeycluster","containerName":"ping-app","hostNetwork":false,"namespace":"default","containerID":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5","podName":"webapp-d87cdd796-tcml8","podNamespace":"default","workloadName":"webapp","workloadNamespace":"default","workloadKind":"Deployment"},"RuntimeProcessDetails":{"processTree":{"pid":11278,"cmdline":"apache2 -DFOREGROUND","comm":"apache2","ppid":11128,"pcomm":"containerd-shim","uid":0,"gid":0,"startTime":"0001-01-01T00:00:00Z","cwd":"/var/www/html","path":"/usr/sbin/apache2"},"containerID":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5"},"event":{"runtime":{"runtimeName":"containerd","containerId":"41df552eada80c2de3779f67b599eece57450a330be252e97d7d0aa3bb41e4d5"},"k8s":{"node":"node-02","namespace":"default","podName":"webapp-d87cdd796-tcml8","podLabels":{"app":"webapp","pod-template-hash":"d87cdd796"},"containerName":"ping-app","owner":{}},"timestamp":1747248283133316166,"type":"normal"},"level":"error","message":"Unexpected system call: tkill","msg":"Unexpected system call","time":"2025-05-14T18:44:43Z"}

Analysis:

syscall":"tkill is likely harmless and {"syscall":"gettid"} is a known difference between k8s and k3s (dont ask me why)

Otherwise there are only the start/stop notices. So: in this case: our test is accepted. HURRAY

kubectl delete -f bob.test

Merging multiple BoBs

Lets talk about how BoBs must be additive and composable .

And also how they must be customizable to the clients different environments.

bob merge

TODO C: we need to collect the kubescape output and present it to the user, e.g. informing them about this known 1 syscall difference. The patching is highly suboptimal this way, think of it as a sketch, please

in this case, our customer , on preprod, would now add the allowed syscall into the bob:

kubectl patch applicationprofile \
replicaset-webapp-d87cdd796 --type='json'\
 -p='[{"op": "add", "path": "/spec/containers/0/syscalls/-", "value":"gettid"}]'

TODO: For this lab to work we need to publish our bob into some registry that will survive the playground switching.
