Validate CSI Storage Performance Using FIO and a Kubernetes Job

Omkar Shelke
by  Omkar Shelke

Scenario

You are working on a Kubernetes cluster where storage performance needs to be validated using a CSI-backed StorageClass. The cluster has the local-path StorageClass available, backed by the local-path-provisioner CSI driver.

Before deploying stateful workloads, the team needs to benchmark the underlying storage performance — specifically random write I/O — using FIO (Flexible I/O Tester), a standard Linux storage benchmarking tool.

Task

Create a PersistentVolumeClaim named app-data-pvc in the storage-lab namespace using the StorageClass local-path with a requested size of 1Gi.

Then create a Job named storage-check in the storage-lab namespace using the image lfedge/eden-fio-tests:1b1b353 that:

  • Mounts the PVC at /data using a volume named data-vol
  • Is scheduled on node cplane-01 using nodeSelector with key kubernetes.io/hostname
  • The Job runs only once.
  • The Job does not restart after completion.
  • Runs the following FIO benchmark command:
fio --name=randwrite --filename=/data/testfile --size=1G --bs=4k --rw=randwrite --runtime=25 --time_based --direct=1 --output=/data/fio-result.txt && cat /data/fio-result.txt

After creating the resources, the FIO benchmark runs for 25 seconds — the Job will take approximately 1 minute to fully complete.

Wait until the Pod shows Completed status before checking the logs or verifying the report file.

Use kubectl get pod -n storage-lab -l job-name=storage-check -w to watch the Pod status in real time.

Hint

Create a PVC in the storage-lab namespace with storageClassName: local-path and accessModes: ReadWriteOnce. ReadWriteOnce is the only supported access mode for local-path because the volume is stored directly on the local disk of cplane-01 — only one node can mount it at a time.

Set completions: 1 and restartPolicy: Never to ensure the Job runs once and does not retry. Use nodeSelector with key kubernetes.io/hostname to pin the Pod to cplane-01. Name the volume data-vol and mount it at /data. Use --output=/data/fio-result.txt && cat /data/fio-result.txt so the report is both saved on the PVC and visible in kubectl logs.

See the official docs:

Test Cases
