Deploy a Pod with a Container Image from a Private Registry

An nginx:alpine container image is available in a private registry at registry.iximiuz.com. Your task is to deploy a Kubernetes Pod using this image and ensure it can serve requests successfully.

The registry requires authentication with the following credentials:

Username: iximiuzlabs
Password: rules!

Since the image is hosted in a private registry, Kubernetes must be provided with the proper credentials to pull it. You will need to:

Configure authentication credentials for the private registry
Create a Pod that uses these credentials to pull the image
Verify that the Pod is running and serving the default Nginx welcome page

Success criteria:

A Pod named nginx-1 exists in the default namespace
The Pod uses the registry.iximiuz.com/nginx:alpine image
The Nginx server in the Pod responds with the welcome page

Hint 1: Private Registry Access in Kubernetes 💡

When Kubernetes needs to pull images from private registries, it requires authentication credentials.

Kubernetes stores these credentials as Secrets of a special type called kubernetes.io/dockerconfigjson. This secret format is compatible with Docker's authentication configuration.

The most common approaches are:

Use kubectl create secret docker-registry command
Copy existing Docker credentials from ~/.docker/config.json
Create the secret manually using a YAML manifest

Check the official Kubernetes documentation for detailed examples.

Hint 2: Creating a Registry Secret in the Command Line 💡

You can create a registry authentication secret using the kubectl create secret command with the docker-registry type:

kubectl create secret docker-registry SECRET_NAME \
  --docker-server=REGISTRY_DOMAIN \
  --docker-username=REGISTRY_USERNAME \
  --docker-password=REGISTRY_PASSWORD \
  --namespace=POD_NAMESPACE

The secret will contain the encoded credentials that Kubernetes can use to authenticate with the registry.

Providing your secret as a command line argument may result in it being recorded in your shell history. While it's not an issue for this challenge, you likely want to avoid this in production.

Hint 3: Creating a Registry Secret from a Docker Config File 💡

An alternative approach is to copy your existing Docker credentials from ~/.docker/config.json and use them to create a Kubernetes Secret.

kubectl create secret generic SECRET_NAME \
  --from-file=.dockerconfigjson=$HOME/.docker/config.json \
  --type=kubernetes.io/dockerconfigjson

Note that the above command uses a generic secret type in its argument list (instead of docker-registry), but additionally provides the --type=kubernetes.io/dockerconfigjson flag.

The gotcha of this approach is that you need to have the ~/.docker/config.json file available on your machine, and it should contain only the credentials for the registry your Pod needs (because ~/.docker/config.json may have entries for other registries).

Hint 4: Creating a Registry Secret with a YAML Manifest 💡

The most flexible approach is to create a registry secret from a YAML manifest. For that, you'd need to base64 encode the (relevant part of) ~/.docker/config.json file, and then prepare the following YAML manifest:

my-registry-access-secret.yaml

apiVersion: v1
kind: Secret
metadata:
  name: SECRET_NAME
  namespace: POD_NAMESPACE
type: kubernetes.io/dockerconfigjson
data:
  .dockerconfigjson: BASE64_ENCODED_DOCKER_CONFIG_JSON

Once the manifest is ready, you can use the standard kubectl apply command to create the secret:

kubectl apply -f my-registry-access-secret.yaml

Hint 5: Using a Registry Secret in a Pod Spec 💡

To make a Pod use a registry secret to pull images, you need to reference it in the Pod specification using the imagePullSecrets field:

apiVersion: v1
kind: Pod
metadata:
  name: POD_NAME
spec:
  containers:
  - name: CONTAINER_NAME
    image: PRIVATE_IMAGE
  imagePullSecrets:
  - name: SECRET_NAME

Once you have referenced the right secret in the Pod spec, Kubernetes should be able to pull the image from the private registry.

Hint 6: Troubleshooting Image Pull Issues 💡

If your Pod is stuck with ImagePullBackOff or ErrImagePull status, use these commands to diagnose:

kubectl describe pod POD_NAME
kubectl get events --sort-by='.lastTimestamp'

To review the content of the registry secret, you can use:

kubectl get secret SECRET_NAME -o jsonpath='{.data}'
