Klustered: Level Two

Welcome to Klustered: Level Two. This time the app is closer to alive, but the cluster has been booby-trapped so a normal rollout will not behave normally.

The Goal

Open the App tab in the playground UI. You need the Klustered deployment running the v2 image. When everything is fixed, the app will serve a lovely quote and Rawkode's victory dance.

Two Ways to Play

Hard Mode. Treat it like a production rollout gone weird. Try to ship v2, read the errors, and fix only what blocks you.
Guided Mode. Work through the traps one at a time. This level is about comparing desired state with live state and understanding what really happens during a Deployment rollout.

Getting Started

You'll be working from cplane-01. The admin kubeconfig is only readable by root, so switch users first:

sudo su

Quick sanity check:

kubectl get nodes

If kubectl returns a permission or auth error, double-check that you became root before continuing.

Hard Mode

You're on cplane-01. The Service already points at the app, but a plain v1 -> v2 rollout is blocked by several planted cluster problems. Use the normal tools: kubectl get, kubectl describe, kubectl rollout status, kubectl get events, and the App tab.

Stop reading here if you want the full challenge.

Guided Mode

There are three planted bugs between you and a clean rollout, plus the final v2 upgrade. The first bug is hidden in the state of the existing pod. The next two only really show themselves during the rollout.

For each step, try the observation prompts first. Only open the hint blocks when you're stuck. They spoil the answer in stages: nudge, then concept, then fix.

Step 0: Get the Lay of the Land

Before changing anything, look at what exists.

kubectl get deployments,pods,services,endpoints
kubectl get events --sort-by=.lastTimestamp
curl -s http://localhost:30000

What to Notice:

Is the klustered pod running?
Does the klustered Service have endpoints? (kubectl get endpoints klustered)
Is the database pod running, and does the postgres Service have endpoints?
Which image is the deployment using?
If the app responds, does it show a quote, or does it report a database connection error?

Step 1: What is a Subresource?

The existing pod was created by a Deployment, so it should look like the Deployment's pod template. Before changing the image, check whether the controller's desired state and the live pod's current state still line up.

Start with the owner and the live object:

kubectl describe pod -l app=klustered
kubectl get pod -l app=klustered -oyaml
kubectl get deploy klustered -oyaml

What to Notice:

Is the pod controlled by the klustered Deployment's ReplicaSet?
Do the live pod's container settings match the Deployment template?
Does kubectl describe pod show any unusual status, conditions, or recent events?

Hint 1: Where to Look

The suspicious field is not on the Service or Deployment selector. It is inside the live pod's container resources.

Compare the pod's spec.containers[].resources with the Deployment's spec.template.spec.containers[].resources.

kubectl get pod -l app=klustered -o jsonpath='{.items[0].spec.containers[0].resources}{"\n"}'
kubectl get deploy klustered -o jsonpath='{.spec.template.spec.containers[0].resources}{"\n"}'

Hint 2: The Concept

Kubernetes supports in-place pod resizing. A pod's resource requests and limits can be changed through the resize subresource without editing the owning Deployment.

That is useful when done intentionally, but it also creates a trap: the pod you are looking at is no longer a clean copy of the Deployment template. The Deployment still describes modest resources, while the live pod has been mutated to request 32Gi of memory with a 64Gi limit.

Hint 3: The Fix

There are two reasonable ways out:

Patch the live pod back to the resources declared by the Deployment template.
Delete the pod and let the Deployment recreate it from the clean template.

In this challenge, pod creation has another trap waiting for you, so patching in place lets you fix this problem without depending on a replacement pod yet. Use the pod name from kubectl get pods:

kubectl patch pod <pod-name> \
  --subresource resize \
  -p '{"spec":{"containers":[{"name":"klustered","resources":{"requests":{"memory":"128Mi","cpu":"100m"},"limits":{"memory":"256Mi","cpu":"500m"}}}]}}'

Then check it again:

kubectl describe pod -l app=klustered
kubectl get pod -l app=klustered -o jsonpath='{.items[0].spec.containers[0].resources}{"\n"}'

If you choose to delete the pod instead and it does not come back, keep going. That failure is the next thing to investigate.

kubectl delete pod -l app=klustered

Step 2: Rollout & Reconcile

Now try to roll the app forward. If it does not complete, stop and inspect what Kubernetes tried to do next:

kubectl set image deployment/klustered klustered=ghcr.io/rawkode-academy/klustered:v2
kubectl rollout status deployment/klustered --timeout=30s

Compare the desired state with what the controllers actually created:

kubectl get deployments,replicasets,pods
kubectl describe deploy klustered
kubectl describe rs -l app=klustered
kubectl get events --sort-by=.lastTimestamp

What to Notice:

Did the Deployment template change to v2?
Did a new ReplicaSet appear?
If there is a new ReplicaSet, did it create a replacement pod?
Do the events show an API rejection yet, or is something simply not reconciling?

Hint 1: Where to Look

If desired state changed but nothing is bringing actual state along with it, look outside the application namespace. The component that runs Deployment and ReplicaSet reconciliation lives in kube-system.

kubectl -n kube-system get pods -o wide
kubectl -n kube-system get pods | grep controller-manager

Then inspect that pod and its logs:

kubectl -n kube-system describe pod -l component=kube-controller-manager
kubectl -n kube-system logs -l component=kube-controller-manager --tail=100

If the label selector does not match in your cluster, copy the controller-manager pod name from the kubectl get pods output.

Hint 2: The Concept

The API server stores the new desired state when you run kubectl set image, but it does not perform the rollout itself. The controller manager runs the reconciliation loops that notice changed Deployments, create ReplicaSets, and make ReplicaSets create Pods.

kube-controller-manager has a --controllers flag. Kubernetes documents that * enables default controllers and -foo disables a named controller. In this scenario, that flag has been changed so ReplicaSets cannot reconcile their Pods.

Hint 3: The Fix

Inspect the controller-manager static pod manifest and remove ,-replicaset-controller from the --controllers argument:

grep -n -- "--controllers" /etc/kubernetes/manifests/kube-controller-manager*.yaml
sed -i.bak 's/,-replicaset-controller//g' /etc/kubernetes/manifests/kube-controller-manager*.yaml
grep -n -- "--controllers" /etc/kubernetes/manifests/kube-controller-manager*.yaml

The kubelet should restart the static pod after the manifest changes. Watch it come back:

kubectl -n kube-system get pods | grep controller-manager
kubectl rollout status deployment/klustered --timeout=30s

Step 3: Validation is Important

Once the controllers are reconciling again, inspect the rollout one more time:

kubectl get deployments,replicasets,pods
kubectl get events --sort-by=.lastTimestamp

This time there should be an explicit failure message in the event stream. Read it carefully before changing anything else.

Hint 1: Where to Look

The error message mentions that only pods whose names start with kube- may be created. That is not a scheduler problem, and it is not an image pull problem.

Look for admission resources:

kubectl get validatingadmissionpolicies,validatingadmissionpolicybindings

Hint 2: The Concept

A ValidatingAdmissionPolicy can reject API requests before objects are persisted. In this level, the policy targets CREATE operations for pods in the default namespace.

Deployments do not update a running container in place when you change the image. They create a new ReplicaSet, and that ReplicaSet creates new pods. The policy denies those new klustered-* pods because their names do not start with kube-.

Hint 3: The Fix

Remove the binding first, then the policy:

kubectl delete validatingadmissionpolicybinding namespace-guard-binding
kubectl delete validatingadmissionpolicy namespace-guard

If your rollout was already started, Kubernetes should retry once the admission policy is gone. If it does not, restart the rollout command:

kubectl rollout status deployment/klustered

Step 4: Let's Ship

With the blockers removed, roll the Deployment forward:

kubectl set image deployment/klustered klustered=ghcr.io/rawkode-academy/klustered:v2
kubectl rollout status deployment/klustered

If you already ran kubectl set image in Step 2, you do not need to run it again. Just watch the rollout finish.

Refresh the App tab. Dance party.
