Welcome to Klustered: Level One. Someone left this cluster in a thoroughly broken state, and you've been handed the keys. Your job: fix it.
The Goal
Open the App tab in the playground UI. Right now it's blank, because nothing is reachable. You're aiming for two milestones:
- The app comes back to life. Once you've patched up the cluster, the App tab will show Rawkode tapping his watch, as if to say "any day now". The plumbing works, but you're still on the old version. Halfway there.
- The
v2upgrade lands. Roll the deployment forward to thev2image and the watch-tapping is replaced with Rawkode's victory dance. That's the win.
Visually, you'll know you're done when the dancing starts.
Two Ways to Play
- Hard mode. Just get it working. No hints, no peeking.
- Guided mode. Work through it step by step, with each bug framed as a learning opportunity.
Pick your path below.
Getting Started
You'll be working from cplane-01. The admin kubeconfig is only readable by root, so the very first thing to do is switch users:
sudo su
Quick sanity check (you should see a node listed):
kubectl get nodes
If you get a permission or auth error, double-check you actually became root before running kubectl.
Hard Mode
You're on cplane-01. The cluster has several distinct problems: some obvious, some sneaky. Reach for whatever kubectl you'd use in the wild (get, describe, logs, events, explain) and keep the App tab open in another window so you can see the watch-tap appear when you get close.
Stop reading here if you want the full challenge.
Guided Mode
There are three planted bugs standing between you and a working cluster, plus a final step to actually perform the v1 -> v2 upgrade that the challenge is named after. Each bug teaches something different about Kubernetes. Work through them in order, or jump around if you spot something faster.
For each step, try the observation prompts first. Only open the hint blocks when you're stuck. They spoil the answer in stages: nudge, then concept, then fix.
Step 0: Get the Lay of the Land
Before changing anything, look at what exists.
kubectl get pods,svc,deploy
kubectl get events --sort-by=.lastTimestamp
What to notice:
- Which pods are
Running? Which are not, and what state are they stuck in? - Does the
klusteredservice have endpoints? (kubectl get endpoints klustered) - Can you reach the app at all? (
curl -s http://localhost:30000) - And out of curiosity, what does the App tab show right now? (Spoiler: not Rawkode, not yet.)
You should see at least one pod that never becomes Running, and a service with no endpoints. Those are two separate problems. There are more once you start digging.
Step 1: The Database Pod That Won't Schedule
Run kubectl get pods. The database-* pod is stuck in Pending. Normally that means insufficient resources or a taint, but kubectl describe pod will tell you the real reason.
Hint 1: Where to Look
Look at the Status and Conditions on the pod, and the spec of the deployment. The pod isn't waiting for a node. The scheduler has been told not to try yet.
Hint 2: The Concept
Kubernetes 1.27+ introduced scheduling gates. A pod can declare spec.schedulingGates, and the scheduler will refuse to place it until every gate is removed. Gates are normally removed by an external controller (quota system, admission webhook, etc.) once its precondition is satisfied.
This deployment declares a gate (example.com/quota-check) but no controller exists to remove it. The pod is gated forever.
Hint 3: The Fix
Edit the deployment and remove the schedulingGates block from the pod template:
kubectl edit deployment database
# delete the schedulingGates: ... lines under spec.template.spec
The pod should immediately schedule and start.
Step 2: The Service Points to Nobody
curl http://localhost:30000 returns nothing. Check the wiring:
kubectl get svc klustered
kubectl get endpoints klustered
The Service exists, the klustered pod is Running, but endpoints shows <none>. A Service with no endpoints is a Service that routes traffic to thin air.
Hint 1: Where to Look
A Service finds its pods by label selector. Look at the labels on the pod (kubectl get pod -l app=klustered) and the selector on the Service (kubectl get svc klustered -o yaml). Compare them character by character.
Hint 2: The Concept
Service selectors are literal string matches. There's no fuzzy matching, no warning if no pod matches. You just get an empty Endpoints list and a Service that silently routes to nothing. This is one of the most common "everything looks right" bugs in Kubernetes, and a great reminder to always check kubectl get endpoints when a Service "doesn't work".
Hint 3: The Fix
The Service selector is app: klustred, missing an e. Fix it:
kubectl edit svc klustered
# change selector: app: klustred -> app: klustered
kubectl get endpoints klustered should now show the pod IP. Try curl http://localhost:30000 again. It probably reaches the pod now, but the response isn't what you'd hope for. Onward.
Step 3: The App Can Resolve Nothing
The Service is wired up, the pod is running, but the page either errors out or hangs. That means traffic is getting to the app, and the app itself is unhappy. Time to look at the logs:
kubectl logs deploy/klustered
You'll likely see DNS resolution failures for postgres. But postgres is a perfectly valid Service in this namespace, and nslookup postgres from another pod works fine. So why can't this pod resolve it?
Hint 1: Where to Look
Compare the klustered deployment's pod spec to the database deployment's pod spec. There's a field on one that isn't on the other, and it changes how the pod's /etc/resolv.conf gets built.
Hint 2: The Concept
dnsPolicy controls which resolver a pod inherits:
ClusterFirst(the default): pods use CoreDNS, so Service names likepostgresresolve.Default: pods inherit the node's/etc/resolv.conf, which knows nothing about cluster Services.
The klustered deployment has dnsPolicy: Default, so its pod skips CoreDNS entirely and can't find postgres.
Hint 3: The Fix
Remove the dnsPolicy: Default line from the deployment (the default is ClusterFirst), or set it explicitly:
kubectl edit deployment klustered
# remove the dnsPolicy: Default line, or change to ClusterFirst
Flip over to the App tab. You should see Rawkode tapping his watch. The app is alive, just running the wrong version. One more bug between you and the dance floor.
Step 4: Final Step (Ship v2)
This is the actual goal of the level. Everything up to now was just clearing rubble so you could do this safely. The cluster is healthy, the app is serving, Rawkode is tapping his watch on the App tab. Time to roll the deployment forward and unlock the dance.
Hint 1: The Concept
A Deployment's pod template is the source of truth for what gets run. Change the image tag in the template and Kubernetes performs a rolling update: it spins up a new ReplicaSet, scales it up, scales the old one down, and (if anything goes wrong) you can kubectl rollout undo your way back.
You can do this two ways: edit the manifest directly with kubectl edit, or use the imperative shortcut kubectl set image. Both produce the same result. The former is closer to GitOps-style workflows; the latter is faster at the keyboard.
Hint 2: The Rollout
kubectl set image deployment/klustered klustered=ghcr.io/rawkode-academy/klustered:v2
kubectl rollout status deployment/klustered
Or kubectl edit deployment klustered and change :v1 to :v2.
Refresh the App tab. Dance party.
