Challenge, Easy,  on  Kubernetes, Networking

Kubernetes Ingress: Expose Multiple HTTP Backends the Imperative Way

Three teams share the same Kubernetes cluster, each running their service in a separate namespace. Your job is to expose each service at its own hostname using Ingress resources, with Traefik as the ingress controller.

Verify what is already running:

kubectl get pods -A | grep app

kubectl get svc -A | grep app-svc

kubectl get ingressclass

Step 1 - Create an Ingress for Each Team

Create an Ingress named app-ingress in each team namespace.

Requirements:

  • ingressClassName: traefik
  • team-v1/app-ingress: host app-v1.local, path / - backend app-svc:5678 (pathType: Prefix)
  • team-v2/app-ingress: host app-v2.local, path / - backend app-svc:5678 (pathType: Prefix)
  • team-v3/app-ingress: host app-v3.local, path / - backend app-svc:5678 (pathType: Prefix)
Hint: Creating an Ingress imperatively

Personally, I find imperative commands much easier to memorize than YAML file structure and I use them whenever I can. kubectl create ingress covers all the fields you need. Run kubectl create ingress --help to see all flags. The --rule format is host/path=service:port — append * to the path to get pathType: Prefix.

Step 2 - Verify Traffic

Test each team's service by sending a request to Traefik on port 80 with the correct Host header:

curl -H "Host: app-v1.local" http://localhost/

curl -H "Host: app-v2.local" http://localhost/

curl -H "Host: app-v3.local" http://localhost/

Step 3 - Path-Based Ingress with a Catch-All Rule

The platform namespace has three services: api, admin, and frontend. Create a single Ingress named path-ingress in platform that routes by path instead of hostname.

Unlike the host-based Ingresses above, all backends are in the same namespace so one Ingress can reference all three.

Requirements:

  • ingressClassName: traefik
  • host app.local, path /api - backend api:5678 (pathType: Prefix)
  • host app.local, path /admin - backend admin:5678 (pathType: Prefix)
  • host app.local, path / - backend frontend:5678 (pathType: Prefix, catch-all)

Step 4 - Verify Path Routing

curl -H "Host: app.local" http://localhost/api

curl -H "Host: app.local" http://localhost/admin

curl -H "Host: app.local" http://localhost/unknown
