Extend the Cluster with an Additional Service CIDR for the dev Team

Omkar Shelke
by  Omkar Shelke

Scenario

The cluster currently allocates all Service ClusterIPs from a single default range. The dev team needs its own dedicated pool of Service IPs, but reconfiguring the cluster's existing default Service CIDR is disruptive — it requires editing the kube-apiserver manifest, restarting the apiserver, and potentially recreating every existing Service.

Modern Kubernetes (1.33+) solves this with the ServiceCIDR API object — an additional, completely separate IP range can be added for Services without touching the default range or restarting anything.

A web-app Deployment is already running in the dev namespace, but it has no Service yet.

Task

  1. Add a new ServiceCIDR object named dev-team-cidr for 192.168.0.0/24, without modifying the existing default ServiceCIDR. Wait for it to report Ready: True
  2. Create a Service named web-app-svc in the dev namespace that selects pods with the label app: web-app. Configure spec.clusterIP with a valid IP address from the 192.168.0.0/24 Service CIDR. Do not use the network address (192.168.0.0) or the broadcast address (192.168.0.255).
  3. Confirm from inside a pod that DNS resolves web-app-svc.dev.svc.cluster.local to the Service's ClusterIP and that the application responds with its custom message.
Hint 1 — Inspect the Existing Default ServiceCIDR First

Before creating anything new, take a look at what the cluster already has. There is a built-in ServiceCIDR object that was created automatically at cluster bootstrap — find it, read its CIDR, and make sure you understand its name. You'll need to leave it completely untouched.

kubectl get servicecidr
kubectl get servicecidr <name> -o yaml

Documentation

Hint 2 — Create a New ServiceCIDR Object

A ServiceCIDR is a cluster-scoped resource under networking.k8s.io/v1. Create one named dev-team-cidr that covers 192.168.0.0/24. The relevant field to set is spec.cidrs.

After applying it, don't move on immediately — check its status.conditions and wait until the Ready condition shows True. Only then will the API server accept Service IPs from this range.

kubectl describe servicecidr dev-team-cidr

Documentation

Hint 3 — Think Carefully About How Kubernetes Assigns ClusterIPs

This is the trickiest part of the challenge. The Kubernetes IP allocator does not prefer a newly added ServiceCIDR over the default one — it picks from a shared pool, so a Service created without a specific IP will almost certainly land in the default range, not 192.168.0.0/24.

To guarantee the Service gets an IP from the new range, pick any valid ClusterIP from inside 192.168.0.0/24 and set it explicitly on the Service using the spec.clusterIP field. The valid ClusterIP range for a /24 is .1 through .254 — avoid .0 (network address) and .255 (outside the usable range).

Documentation

Hint 4 — Verify DNS and Connectivity from Inside the Cluster

Always verify DNS and connectivity from a pod running inside the cluster — not from the host — since that is the actual path real workloads use. Use a temporary busybox pod for the DNS lookup and a curlimages/curl pod for the HTTP request, both in the dev namespace so they share the same DNS search domain as the Service:

kubectl run dns-test --rm -it --restart=Never \
  --image=busybox:latest -n dev -- nslookup web-app-svc.dev.svc.cluster.local

kubectl run curl-test --rm -it --restart=Never \
  --image=curlimages/curl:latest -n dev -- \
  curl http://web-app-svc.dev.svc.cluster.local

Documentation
